Fan-type pocket reduction-scale ruler, Faber-Castell 20/83

Object/Artifact

A folding "fan" scale rule: five flat steel scale blades riveted at one end into a green leather case/holder, fanning open like blades of a pocketknife. Each blade is printed in black on a light (white/silvered) ground with paired reduction scales and fine graduations; visible ratios across the blades include 1:20, 1:25, 1:30, 1:33⅓, 1:50, 1:100, 1:110, 1:115, 1:125, 1:130, 1:140, 1:150, and 1:175. The uppermost blade is marked "Faber-Castell 20-83 W.Germany." Closed, the blades nest within the green leather sheath, which has a thumb-notch and a riveted pivot at the head.

2025.16.4

Evelyn Sosa collection

2025.16

Evelyn Sosa

Gift

A.W. Faber-Castell

F.R.G.

Central Europe

Europe

Model 20/83

Date: West German era — manufactured 1949–1990 per the "W. Germany" mark (pre-reunification). Circa 1960s–1980s (tentative). Place of Origin: West Germany (Faber-Castell); imported to and used in Cuba.

"Faber-Castell 20-83 W.Germany" on a blade; printed reduction-scale ratios and graduations on each blade (range 1:20 to 1:175).

Materials: Coated/printed steel scale blades; green leather (or leatherette) case; metal pivot rivet. Technique: Precision-printed/engraved steel scales; stitched leather case; riveted fan pivot allowing the blades to swing out individually.

Good

F.R.G.

Central Europe

Europe

production

Havana

Cuba

Caribbean

Central America

use
